Home » Metal Ceilings » Gas Station Ceilings » C-CA GS SERIES exterior linear metal ceiling closed
Escape is the T24 lay-in metal ceiling system properly conceived for environment renewal. Metal panels, in fact, can be installed on the existing T24 grid by concealing it partially. When installed a 6mm closed shutter is visible and it marks the modular shape of the Escape metal panels.

Enigma Escape is made up of right edge, 600x600 mm panels to be laid on Fox T24 structure, which remains in the background, while panels stand out, by enhancing the modular design of the ceiling. Fox T24 profiles are available in white, black and silver colours, while panels, in addition to white and silver colours, can be made in RAL /NCS coating, and their metal surface can be enriched with faithful reproduction of images and natural material appearance such as woods or natural stones. Through digital printing and sublimation process, in fact, pictures can be actually reproduced on the metal surface making amazing the skin of the metal ceilings.

Enigma Escape is also an optimal choice to realize acoustic ceilings. To achieve the conceived acoustic performance, panels can be perforated with seventeen standard perforation pattern and coupled with three different acoustic pad, such as black ​fleece, mineral soft padding or rock-wool insulation. In comparison with other materials the acoustic metal panels can reach a proper balance between sound absorption and reflection improving reverberation time index and speech intelligibility.

Installation is quick and easy, therefore the system can be realized in few simple steps.
And for plenum access and plant maintenance panels can be removed, by simply pushing them upwards. Enigma Escape is a very appreciated lay-in ceiling system generally used in office, shops, hotels and restaurants to ​improve the environment design using a standard metal ceiling with semi-concealed T-gridceilingstructure.  Moreover, to be installed in seismic area, Fox T24 can be reinforced with proper anti-seismic kits: numbers, types and positions are indicated in specific report to be required at offer stage. Anti-seismic kits must be set according to project requirements, place of installations, ceiling features, plenum high and other specific aspects. Properly conceived to realize high performance T24 metal ceiling, Escape system can be perfectly integrated with lightnings, air flow panels, plant accessories and standard or custom made wall angle veils, enhancing the overall aesthetics of the ceiling.

FEATURES:
Clip-in metal panels | syde by syde
Right Edge | 600×600 mm
other dimensions on request.

MATERIALS:
Aluminium 5-6-7/10 | Steel 5-6/10

STRUCTURE:
FOX T24

ANTISEISMIC EQUIPMENT:
Antiseismic kit for standard plenum < 1,2 m
Antiseismic kit for high plenum > 1,2 m

COLORS | FINISHING | PERFORATIONS:
White – silver pre-painted aluminum
White – silver pre-painted steel
RAL/NCS Coating
Wood finishing | Water effect
Sublimation and digital printing
Plain or perforated surface.
