Enigma Escape
is made up of right edge, 600x600 mm panels to be laid on Fox T24
structure, which remains in the background, while panels stand out, by enhancing
the modular design of the ceiling. Fox T24 profiles are available
in white, black and silver colours, while panels, in addition to white and
silver colours, can be made in RAL /NCS coating, and their metal surface can be
enriched with faithful reproduction of images and natural material appearance
such as woods or natural stones. Through digital printing and sublimation
process, in fact, pictures can be actually reproduced on the metal surface
making amazing the skin of the metal ceilings.
Enigma Escape is also an optimal
choice to realize acoustic ceilings. To achieve the conceived acoustic
performance, panels can be perforated with seventeen standard perforation
pattern and coupled with three different acoustic pad, such as black fleece,
mineral soft padding or rock-wool insulation. In comparison with other
materials the acoustic metal panels can reach a proper balance between
sound absorption and reflection improving reverberation time index and speech
intelligibility.
Installation is quick and easy, therefore the system can be realized in few
simple steps.
And for plenum access and plant maintenance panels can be removed, by simply
pushing them upwards. Enigma Escape is a very appreciated lay-in ceiling system generally
used in office, shops, hotels and restaurants to improve the environment
design using a standard metal ceiling with semi-concealed T-gridceilingstructure. Moreover, to be installed in seismic area, Fox
T24 can be reinforced with proper anti-seismic kits: numbers, types and
positions are indicated in specific report to be required at offer stage. Anti-seismic
kits must be set according to project requirements, place of installations,
ceiling features, plenum high and other specific aspects. Properly
conceived to realize high performance T24 metal ceiling, Escape system
can be perfectly integrated with lightnings, air flow panels, plant accessories
and standard or custom made wall angle veils, enhancing the overall aesthetics
of the ceiling.
FEATURES:
Clip-in metal panels | syde by syde
Right Edge | 600×600 mm
other dimensions on request.
MATERIALS:
Aluminium 5-6-7/10 | Steel 5-6/10
STRUCTURE:
FOX T24
ANTISEISMIC EQUIPMENT:
Antiseismic kit for standard plenum < 1,2 m
Antiseismic kit for high plenum > 1,2 m
COLORS | FINISHING | PERFORATIONS:
White – silver pre-painted aluminum
White – silver pre-painted steel
RAL/NCS Coating
Wood finishing | Water effect
Sublimation and digital printing
Plain or perforated surface.
