Home » Metal Ceilings » Staves ceilings » S MULTILEVEL 3D LINE SERIES multi panel ceiling system
The S Multilevel 3D Line multi panel metal ceiling system is made up of S-staves of different heights and widths, which, thanks to their modularity, offer unlimited configuration possibilities. The variety of heights and bases makes it possible to create a personalised ceiling with movement and a three-dimensional look.

S MULTILEVEL 3D LINE multi panel ceiling system is unique in that, it can be purchased in classic white and silver or customised in RAL colours.

 ​S MULTILEVEL 3D LINE metal panels for ceiling are also available in smooth or perforated versions: Ø ≥ 0.75 ≤ 1.5 mm perforations parallel or diagonal (perforated base over the edge, perforated on three sides, perforated base with plain edge); Ø ≥ 1.8 ≤ 2 mm perforations parallel or diagonal (perforated base with plain edge, perforated on three sides with plain edge). ​ S MULTILEVEL 3D LINE metal panels for ceiling are installed with a special carrier with a locking system that is safe and easy to install, leaving a 20-mm gap between the staves.

In this particular configuration,
there are four types of staves that can be used to create a three-dimensional ceiling:
BASE 30 (H 14/38/80/100), BASE 80 (H 14/80/100), BASE 130 (H14/80/100)
and BASE 180 (H14/80/100).

S MULTILEVEL 3D LINE metal panels for ceiling are made of aluminium or steel; the system is equipped as standard with double spring hangers and includes joints for staves, carriers and "L", "Double L", "C" perimeter profiles, generally made in the same color and finishing of the ceiling system. Considering that the maximum length of the carrier is 4.000 mm, this metal ceiling is perfect for use in large areas such as shopping centres, airports and railway stations.

S MULTILEVEL 3D LINE multi panel ceiling system provides a sleek and modern look to any space while also offering durability and easy installation. The use of aluminium or steel ensures that the ceiling will withstand the test of time and maintain its aesthetic appeal.

S MULTILEVEL 3D LINE multi panel ceiling:
an ideal choice for large areas that require both functionality and style.

S30  h14 | h38 | h80 | h100
S80  h14 | h80 | h100
S130 h14 | h80 | h100
S180 h14 | h80 | h100
Clip-in staves | Open gap | Right edge

Steel | Aluminium

TS carrier with locking system

Antiseismic kit for standard plenum < 1,2 m
Antiseismic kit for high plenum > 1,2 m

White – silver pre-painted aluminum
White – silver pre-painted steel
RAL/NCS Coating | Wood finishing
Sublimation of any image and effec
Plain or perforated surface.

Product ​Specifcations
